HR 8799 Exoplanet System
About This Image
Caption
Left: This is an image of the star HR 8799 taken by Hubble's Near Infrared Camera and Multi-Object Spectrometer (NICMOS) in 1998. A mask within the camera (coronagraph) blocks most of the light from the star. In addition, software has been used to digitally subtract more starlight. Nevertheless, scattered light from HR 8799 dominates the image, obscuring the faint planets.
Center: Recent, sophisticated software processing of the NICMOS data removes most of the scattered starlight to reveal three planets orbiting HR 8799. Astronomers used this decade-old image to calculate the orbits of the planets.
Right: This is an illustration of the HR 8799 exoplanet system based on the reanalysis of Hubble NICMOS data and ground-based observations. The positions of the star and the orbits of the four known planets are shown schematically. The sizes of the dots are not to scale with the planet's true sizes. The three outermost planets, b, c, and d, are detected in both the NICMOS and ground-based data. A fourth, inner planet, e, was detected in ground-based observations. The orbits appear elongated because of a slight tilt of the plane of the orbits relative to our line of sight. The size of the HR 8799 planetary system is comparable to our solar system, as indicated by the orbit of Neptune, shown to scale.
Credits
NASA, ESA, and R. Soummer (STScI)Keywords
| About The Object | |
|---|---|
| Object Name | HR 8799 |
| Object Description | Star with planets |
| R.A. Position | 23h 7m 28.65s |
| Dec. Position | 21° 8' 3.69" |
| Constellation | Pegasus |
| Distance | 130 light-years or 40 parsecs |
| About The Data | |
| Data Description | The original NICMOS data were from the HST proposal 7226: E. Becklin (University of California, Los Angeles) et al. The science team comprises: R. Soummer, B. Hagan, and A. Rajan (STScI), L. Pueyo and A. Thormann (JHU), and C. Marois (Herzberg Institute of Astrophysics, Victoria). |
| Instrument | HST>NICMOS/NIC2 |
| Exposure Dates | October 30, 1998, Exposure Time: 20 minutes |
| Filters | F160W |
| About The Image | |
| Color Info | This image was originally black and white and recorded only overall brightness. These brightness values were translated into a range of arbitrary colors. Such color "maps" can be useful in helping to distinguish subtly varying brightness in an image. |
